DC 12V 24V to AC 110V 220V Solar On Grid Tie Power Inverter With Voltage Switch 300W 115V/230V Exchange |

DC 12V 24V to AC 110V 220V Solar On Grid Tie Power Inverter With Voltage Switch 300W 115V/230V Exchange |

Brand NameNoneModel NumberTEG-300W-WVTypeDC/AC InvertersSize21*16.5*5.3 cmWeight2kgis_customizedYesInput Voltage10.8V-28V/22V-60VOutput Voltage90V-140/190~260VACOutput PowerOtherOutput TypesingleOutput Frequency55Hz~63Hz/ 45Hz-53HzMeasurement unitpiece/piecesEach pack1

Unavailable in

Description

DC 12V 24V to AC 110V 220V Solar On Grid Tie Power Inverter With Voltage Switch 300W 115V/230V Exchange

  Model:  TEG-300W

u  ‘SGPV’ (Small Grid Tie Photovoltaic System)

l  The only plug and play small grid tie photovoltaic system

l  The stackable small grid tie photovoltaic system

u  INTRODUCTION

  The small type solar grid tie power inverter can obtain the solar energy from solar panel, and can tie to the grid through its output cable with no extra equipment. The installation is very convenient and reliable.

  We call the system combining with small solar grid tie power inverter and solar panels as ‘SGPV’. The system includes solar panels and small type grid tie power inverter. Solar panels can be mono silicon, polygon silicon, non-crystal film or any other material that can transform solar energy to electric energy. The power of grid tie inverter should be matched to the power of solar panels connected. So the power of SGPV is defined by its solar panels, it can be standardization according to the actual using.

  The inverter can be connected to any outlet at home, when this line run by the conventional electric network. The small grid tie monitors the volume, frequency and phase of the home grid, then produce a pure sine wave that the frequency and phase are as same as the grid's, and the volume is a bit higher than the grid's, then according to the current controlled PWM, to control the output power to the grid. The small grid tie inverter just puts out power when the home grid is on.

  When the sun shines, the PV panel will produces DC voltage, and the grid tie inverter will change the DC voltage to AC voltage and puts out power to the home grid. When the total power of electric apparatus that are using in the house is larger than the output power of the inverters, these power from the inverters will be consumed in the house, this will slow down the power meter, otherwise, the difference of the output power of the inverter between the total used power of the apparatus will go out from the house to the out grid.

Layout

INSTALLATION:

  The individual system of SGPV is shown in Figure 1. Installing the solar panel of the SGPV at a suitable location that sunshine can irradiate on it, connecting the cables of the solar panel to the DC input terminals of the small grid tie inverter of the SGPV, inserting the plug of the inverter into the socket of the home grid. After this, when the sun shines, the SGPV will convert the solar energy to the home grid.

Electrical Specifications:

Mechanical Specifications:

-10 ~ 45 degrees C
